Product Introduction


Specifications :

Dimension 288 x 127 x 65 (mm)
Weight 1045gm (with adaptor)
Channel 4 independent isolated transformers(4CH)
Power supply AC/DC 9V/300mA HT77A(4CH)
Output 0~120mA P to P into 500Ω load
Rate 1~100Hz
Function mode
  cycle time on time off time
f1 continue continue 0
f2 4 seconds 2 seconds 2 seconds
f3 8 seconds 4 seconds 4 seconds
Pulse width 250µs (fixed)

Standard Accessories :

Electrical Stimulator 1
Stimulator Lead Wire 4
Self Adhering Electrode 8
Operating Manual 1
9V DC Adaptor 1
Reusable Package 1

TENS electrode application areas :

Indicator and Controls :
